Mitsubishi Electric MFZ-KA25VA User Manual

WALL-MOUNTED Outdoor Unit M series
OUTLINES AND DIMENSIONS
WALL- MOUNTED
Unit: mm
C-22
MU-GD80VB
MUH-GA60VB MUH-GD80VB
OUTDOOR UNIT
155
90
198
40
515
299
66
34
51
330
360
850
430
500
80
121
840
Open as a rule
500 mm or more if
the front and both
sides are open
100 mm or more
200 mm or more if
there are obstacles
to both sides
Open as a rule
500 mm or more if the back,
both sides and top are open
350 mm or more
100 mm or more
Service panel
Gas refrigerant
pipe joint
Refrigerant pipe
(flared) 15.88
Liquid refrigerant
pipe joint
Refrigerant pipe
(flared) 6.35 (MUH-GA60VB)
9.52 (MU(H)-GD80VB)
170
Drain holes 33
4 holes 10 × 21
Air in
Air out
Air in
