WALL-MOUNTED Fixed Speed Heat PumpM series
REFRIGERANT SYSTEM DIAGRAM
WALL- MOUNTED
C-53
Indoor
heat
exchanger
Room temperature
thermistor
RT11
Indoor coil
thermistor
RT12
(with heat insulator)
Refrigerant pipe : 9.52
Refrigerant pipe :6.35
(with heat insulator)
4-way valve
Defrost
thermistor
RT61
Muffler
Outdoor
heat
exchanger
Capillary
(MUH-GA25VB)
(MUH-GA35VB)
tube
:3.0x:1.4x500
:3.0x:1.4x350
Capillary tube
:3.0x:1.4x1000
(MUH-GA25VB)
(MUH-GA35VB)
:3.0x:1.4x400
Check valve
Strainer
#100
Refrigerant flow in cooling
Refrigerant flow in heating
Stop valve
(with service
port)
R.V. coil
heating ON
cooling OFF
Compressor
Stop valve
Capillary tube
:3.0x:1.8x600
(2 pcs)
Indoor
heat
exchanger
Room temperature
thermistor
RT11
Indoor coil
thermistor
RT12
insulator)
pipe : 9.52
4-way valve
Defrost
thermistor
RT61
Muffler
Outdoor
heat
exchanger
Capillary tube
:3.0x:1.4 x 900
Capillary tube
:3.0 x : 1.4 x 300
Check valve
Strainer
#100
Refrigerant pipe :6.35
(with heat insulator)
Stop valve
(with service
port)
R.V. coil
heating ON
cooling OFF
Compressor
Stop valve
(with heat
Refrigerant
Refrigerant flow in cooling
Refrigerant flow in heating
INDOOR UNIT
MSC-GE20VB
OUTDOOR UNIT
MUH-GA20VB
Unit: mm
C.1.4.2 Fixed Speed Heat pump
INDOOR UNIT OUTDOOR UNIT
MSC-GE25VB
MSC-GE35VB
MUH-GA25VB
MUH-GA35VB
