Mitsubishi Electric MSZ-SF20VA User Manual

WALL-MOUNTED Indoor Unit
M series
C-17
OUTLINES AND DIMENSIONS
WALL- MOUNTED
Unit: mm
258
162
19
58
47
7.5
315
255.547
2.5
98
173
98 173414.5 414.5
5
253
791
56
1068
1100
325
Air out
Air in
Insulation 28
Drain hose 16
(Connected part O.D)
Installation plate
Wall hole 75
Wireless remote controller
Installation plate
Indoor unit
{
Liquid line 6.35- 0.5m
Gas line 12-0.43m
Insulation 50 O.D
32 I.D
{
Liquid line 9.52- 0.5m
Gas line 12-0.43m
Insulation 50 O.D
32 I.D
for MS(H)-GE50VB or MS(H)-GA60VB
for MS(H)-GD80VB
Power supply cord
Lead to right 2.0m
Lead to left 1.0m
MS-GE50VB MS-GA60VB MS-GD80VB MSH-GE50VB MSH-GA60VB MSH-GD80VB
INDOOR UNIT
