26
(2) Table of settings items
Set the dip switches SW2 and SW3 as shown in the table below to set the value for the items in the "Setting item" column.
Dip switch
settings
Setting item
Item
code
Unit
Lower
limit
Upper limit
Initial
value
Setting
value
Basic
settings
SW2-10: OFF
SW3-5, 6, 7: OFF
SW3-8, 9, 10: ON
Unit address 105 - 1 8 2
Number of connected GS to M-NET 106 - 0 16 1
AE-200 connection (0: Not connected, 2: Connected) 107 - 0 2 0
Function 1 (Sub sensor: 2, Main sensor: 1, Sub unit: 0) 110 - 0 2 0
M-NET address of main sensor of own tank 111 - 1 50 1
Address of sensor connection unit 112 - 1 51 51
Secondary control availability
(0: Not available 1: Available)
121 - 0 1 0
Basic
settings
SW2-10: OFF
SW3-5~8, 10:
OFF
SW3-9: ON
Model display 0 - - - -
Current time 1 Hour and minutes 0:00 23:59 -
Current inlet water temperature (display function only) c01 ºC - - -
Current outlet water temperature (display function only) c02 ºC - - -
Outdoor temperature (display function only) c03 ºC - - -
Storage tank water temperature (display function only) c04 ºC - - -
Demand control - maximum capacity setting 2 % 0 100 100
Demand control - start time 3 Hour and minutes 0:00 23:59 13:00
Demand control - end time 4 Hour and minutes 0:00 23:59 16:00
Outlet hot water temperature (boiling temperature) 9 ºC 40
Secondary contlol
disabled: 90.0
Secondary contlol
enabled: 80.0
65
High- and low-pressure display interval P 1051 Seconds 0 100 3
Low noise operation - maximum capacity 1054 % 0 100 70
Low noise operation - start time 1058 Hour and minutes 0:00 23:59 0:00
Low noise operation - end time 1059 Hour and minutes 0:00 23:59 0:00
SW2-10: OFF
SW3-5~7, 9, 10:
OFF
SW3-8: ON
Thermo-ON prohibition time Sjs1 1025 Seconds 0 480 60
Sensor method setting
(0: Local control, 1: Three-sensor, 2: Six-sensor)
1214 - 0 2 0
Mode 1 Thermo-ON thermistor selection 1500 - 1
Six-sensor system: 6
Other system: 3
3
Mode 1 Thermo-OFF thermistor selection 1501 - 1
Six-sensor system: 6
Other system: 3
3
Mode 2 Thermo-ON thermistor selection 1502 - 1
Six-sensor system: 6
Other system: 3
1
Mode 2 Thermo-OFF thermistor selection 1503 - 1
Six-sensor system: 6
Other system: 3
2
Mode 3 Thermo-ON thermistor selection 1504 - 1
Six-sensor system: 6
Other system: 3
1
Mode 3 Thermo-OFF thermistor selection 1505 - 1
Six-sensor system: 6
Other system: 3
3
Number of water control modes 1507 - 1 3 1
Mode 1 Thermo differential value 1508 - 0 30 10
Mode 2 Thermo differential value 1509 - 0 30 10
Mode 3 Thermo differential value 1510 - 0 30 10
Anti-freezing setting
(0: Outdoor, 1: Indoor)
1514 - 0 1 0
