Model
Item
FDEN40VF
Power source 220-240V
~
50Hz / 220V
~
60H
Operation data Cooling Heating
Nominal capacity kW 4.0 4.5
Sound Pressure Level dB(A) P-Hi : 46 Hi : 39 Me : 38 Lo : 37
Exterior dimensions
Height × Width × Depth
mm 210 × 1,070 × 690
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Net weight kg 28
Heat exchanger Louver fin & inner grooved tubing
Air handling equipment
Fan type & Q'ty
Centrifugal fan × 2
Motor <Starting method> W 25 < Direct line start >
Air flow (Standard) CMM P-Hi : 11 Hi : 10 Me : 9 Lo : 7
External static pressure Pa 0
Outdoor air intake Not possible
Air filter, Q'ty Pocket plastic net × 2 (Washable)
Shock & vibration absorber Rubber sleeve (for fan motor)
Insulation (noise & heat) Polyurethane form
Remote controller wired : RC-EX1A (option) wired : RC-E5 (option) wireless : RCN-E1R (option)
Room temperature control Thermostat by electronics
Safety equipment
Internal thermostat for fan motor
Frost protection thermostat
Installation data
Refrigerant piping size
mm
Liquid line :
φ
6.35 (1/4")
Gas line :
φ
12.7 (1/2")
Connecting method Flare piping
Drain pump —
Drain Hose Connectable with VP20
Insulation for piping Necessary (both Liquid & Gas lines)
IP code IPXO
Standard Accessories Mounting kit, Drain hose
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PFA003Z954
(b) Ceiling suspended type (FDEN)
