(4) Duct connected-High static pressure type (FDU)
(a) Single type
Model
Item
FDU71VNXVD
Indoor unit FDU71VD Outdoor unit FDC71VNX
—
Power source 220-240V
~
50Hz
Operation data Cooling Heating
Nominal capacity kW 7.1 [ 3.2 (Min.)
~
8.0 (Max.)] 8.0 [ 3.6 (Min.)
~
9.0 (Max.)]
Power consumption kW 2.15 2.15
Running current A 9.6 9.5
Power factor % 98 99
Inrush current A 5 < Max.running current 17 >
Sound Pressure Level dB(A) Hi : 41 Lo : 37 Cooling : 51, Heating : 48
Exterior dimensions
Height × Width × Depth
mm 295 × 850 × 650 750 × 880 (+88) × 340
Exterior appearance
(Munsell color)
—
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg 40 60
Refrigerant equipment
Compressor type & Q'ty
— RMT5118MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.675 (M-MA68)
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Centrifugal fan × 2 Propeller fan × 1
Motor <Starting method> W 230 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM Hi : 20 Lo : 17 Cooling : 60, Heating : 50
External static pressure Pa Standard : 60 Max : 130 0
Outdoor air intake Possible (on return duct) —
Air filter, Q'ty Procure locally —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E5 (option) wireless : RCN-KIT3-E (option)
Room temperature control Thermostat by electronics —
Safety equipment
Internal thermostat for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line : I/U
φ
9.52 (3/8") Pipe
φ
9.52 (3/8") × 0.8 O/U
φ
9.52 (3/8")
Gas line
: I/U
φ
15.88 (5/8") Pipe
φ
15.88 (5/8") × 1.0 O/U
φ
15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length
Max.50m
Vertical height difference between
outdoor unit and indoor
unit
Max.30m (Outdoor unit is higher)
See page 152
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size
φ
20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
IP code IPXO IP24
Standard Accessories Drain hose —
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature
External static pressure
of indoor unit [Pa]
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
60
Heating 20˚C 7˚C 6˚C
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz
(5) External static pressure can be changed from standard external static pressure (factory setting) to maximum external static
pressuer (high static pressure setting) by remote controller.
(6) Value of sound pressure level become increased 5dB(A), when external static pressure is 130Pa.
PJD001Z311
