485
-
'12 • PAC-T-173
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A) <Max. running current> 5 <17>
8.1/8.5
8.5/8.9
1.85
1.95
6.1/6.4
5.9/6.2
2.41
2.33
8.2/8.7
7.9/8.3
3.26
3.11
10.1/10.7
10.1/10.7
4.03
4.02
10.6/11.1
10.3/10.8
2.41
2.33
14.3/15.0
13.7/14.3
3.26
3.11
17.6/18.4
17.6/18.4
4.03
4.02
(220-240V 50Hz/220V 60Hz)
Item
Model
FDC71VNX FDC100VNX FDC125VNX FDC140V NX
kW
A
A
5 <24> 5 <26>
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A) <Max. running current>
(380-415V 50Hz/380V 60Hz)
Item
Model
FDC100VSX FDC125VSX FDC140VSX
kW
A
A
5 <15>
(3) Operation chart
The V Multi is a system that allows for different models and capacities of indoor units to be connected so the individual operating
characteristics of the indoor and outdoor are provided. Use the procedure shown in Item (c) to calculate the combined operating
characteristics.
(a) Operating characteristic of outdoor unit
Note(1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(b) Operating characteristic of indoor unit
Notes(1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
Notes(2) The values shown in the above table are common to both cooling and heating operations.
Model
Item
FDT40VF FDT50VF FDT60VF FDT71VF
Cooling power consumption
kW
0.03-0.03/0.03 0.04-0.04/0.04 0.07-0.07/0.07
0.07-0.07/0.07
Heating power consumption 0.03-0.03/0.03 0.04-0.04/0.04
Cooling running current
A
0.15-0.14/0.15
0.15-0.14/0.15
0.20-0.19/0.20
0.20-0.19/0.20
0.35-0.32/0.35
0.35-0.32/0.35
0.08-0.08/0.08
0.08-0.08/0.08
0.40-0.37/0.40
0.40-0.37/0.40
Heating running current
FDT Series (220-240V 50Hz/220V 60Hz)
Model
Item
FDEN40VF FDEN50VF FDEN60VF FDEN71VF
Cooling power consumption
kW
0.05-0.06/0.06 0.10-0.11/0.11
Heating power consumption 0.05-0.06/0.06 0.09-0.10/0.10
Cooling running current
A
0.25-0.26/0.29 0.46-0.48/0.50
Heating running current 0.23-0.25/0.28 0.42-0.44/0.46
0.11-0.12/0.14
0.10-0.11/0.13
0.50-0.53/0.67
0.46-0.48/0.63
FDEN Series (220-240V 50Hz/220V 60Hz)
