'12 • PAC-T-173
Model
Item
FDT40ZJXVF
Indoor unit FDT40VF Outdoor unit SRC40ZJX-S
Panel T-PSA-3BW-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 4.0 [ 1.1 (Min.) ~ 4.7 (Max.)] 4.5 [ 0.6 (Min.) ~ 5.4 (Max.)]
Power consumption kW 0.930 1.06
Running current A 4.4 / 4.6 5.1 / 5.3
Power factor % 92 / 92 90 / 91
Inrush current A 5 < Max.running current 12 >
Sound Pressure Level dB(A) P-Hi : 39 Hi : 33 Me : 31 Lo : 30 50
Exterior dimensions
Height × Width × Depth
mm
Unit 246 × 840 × 840
Panel 35 × 950 × 950
640 × 800 (+71) × 290
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 22 PANEL 5.5 45
Refrigerant equipment
Compressor type & Q'ty
— RMT5113MCE2 (Twin Rotary type) × 1
Starting method — Direct line start
Refrigerant oil — 0.45 MA68
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Capillary tubes + Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 50 < Direct line start > 34 < Direct line start >
Air flow (Standard) CMM P-Hi : 20 Hi : 18 Me : 16 Lo : 14 Cooling : 36 Heating : 33
Available static pressure Pa 0 0
Outside air intake Possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — —
Remote controller wired : RC-EX1A, RC-E5 (option) wireless : RCN-T-36W-E (option)
Room temperature control Thermostat by electronics —
Safety equipment
Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line : I/U
φ
6.35 (1/4") Pipe
φ
6.35 (1/4") × 0.8 O/U
φ
6.35 (1/4")
Gas line :
φ
12.7 (1/2")
φ
12.7 (1/2") × 0.8
φ
12.7 (1/2")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.30m
Vertical height difference between
outdoor unit and indoor unit
Max.20m (Outdoor unit is higher)
See page 152
Max.20m (Outdoor unit is lower)
Refrigerant Quantity R410A 1.5kg in outdoor unit (incl. the amount for the piping of : 15m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP25 Holes size
φ
20 × 5pcs
Insulation for piping Necessary (both Liquid & Gas lines)
IP code IPXO IPX4
Standard Accessories Mounting kit, Drain hose Drain elbow, Drain hole grommet
1.1 SPECIFICATIONS
(1) Ceiling cassette-4way type (FDT)
(a) Single type
Adapted to RoHS directive
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation these value are somewhat higher due to
ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJF000Z296
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
