1 GENERAL INFORMATION
1.1 Increased indoor unit connection capacity
• Capacity from 50% to 130% is possible
FDCR224KXE6
FDCR280KXE6
1 to 13 units
1 to 16 units
140 ~ 364
112 ~ 292
Number of connectable Connectable capacity
Item
Model
1.2 How to read the model name
(1) Outdoor unit
Example:
FDCR 224 KX E 6
Series No.
Application power source...See the specications
Multi KX series
Nominal capacity (nominal cooling capacity : 22.4kW)
Model name (Outdoor unit)
Note
This unit complies with EN61000-3-3.
For outdoor unit, EN61000-3-2 is not applicable as consent by the utility company or notication to the utility company is given
before usage.
1.3 Branch pipe set and Header pipe set
Total capacity downstream
Less than 180
180 or more but less than 371
Branching pipe set
DIS-22-1G
DIS-180-1G
Total capacity downstream
Less than 180
180 or more but less than 371
Header set model type
HEAD4-22-1G
HEAD6-180-1G
Number of branches
4 branches at the most
6 branches at the most
(1) Branch pipe set (Option)
(2) Header pipe set (Option)
