Model
Item
FDTC125VNPVD
Indoor unit FDTC60VD (2 units) Outdoor unit FDC125VN
Panel TC-PSA-25W-E
Power source 220-240V
~
50Hz / 220V
~
60Hz
Operation data Cooling Heating
Nominal capacity kW 12.5 [ 5.0 (Min.)
~
14.0 (Max.)] 14.0 [ 4.0 (Min.)
~
16.0 (Max.)]
Power consumption kW 5.35 4.62
Running current A 24.0 / 25.1 20.7 / 21.6
Power factor % 97 97
Inrush current A 5 < Max.running current 27 >
Sound Pressure Level dB(A)
Cooling P-Hi : 47 Hi : 46 Me : 39 Lo : 30
Heating P-Hi : 47
Hi : 46 Me : 39 Lo : 32
Cooling : 50 Heating : 51
Exterior dimensions
Height x Width x Depth
mm
Unit 248 × 570 × 570
Panel 35 × 700 × 700
845 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 81
Refrigerant equipment
Compressor type & Q'ty
— RMT5126MDE2 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 M-MA68
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM
Cooling P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 7
Heating P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 8
Cooling : 75, Heating : 73
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment
Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line : I/U
φ
6.35 (1/4")
②φ
9.52 (3/8") x 0.8
①φ
9.52 (3/8") x 0.8 O/U
φ
9.52 (3/8")
Gas line
: I/U
φ
12.7 (1/2")
②φ
12.7 (1/2") x 0.8
①φ
15.88 (5/8") x 1.0 O/U
φ
15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length
Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher)
1.See page 154
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size
φ
20 x 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option).
①
: Pipe of O/U
~
Branch,
②
: Pipe of Branch
~
I/U
(7) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375
A
