Model
Item
FDC71VN
Power source 220-240V
~
50Hz / 220V
~
60Hz
Operation data Cooling Heating
Nominal capacity kW 7.1 [ 3.2 (Min.)
~
8.0 (Max.)] 8.0 [ 3.6 (Min.)
~
9.0 (Max.)]
Sound Pressure Level dB(A) 48
Exterior dimensions
Height x Width x Depth
mm 750 × 968 × 340
Exterior appearance
(Munsell color)
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg 60
Refrigerant equipment
Compressor type & Q'ty
2YC45DXD × 1
Starting method Direct line start
Refrigerant oil 0.65 FVC50K
Heat exchanger Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Propeller fan × 1
Motor <Starting method> W 86 < Direct line start >
Air flow (Standard) CMM Cooling : 60 , Heating : 50
Shock & vibration absorber Rubber sleeve (for Compressor )
Electric heater W 20 (Crank case heater)
Safety equipment
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line :
φ
9.52 (3/8")
Gas line
:
φ
15.88 (5/8")
Connecting method Flare piping
Refrigerant line (one way) length
Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher)
1.See page 154
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain Holes size
φ
20 x 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories —
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(2) Outdoor units
PJF000Z188
A
PJF000Z188
A
