Model
Item
FDUM50ZIXVD
Indoor unit FDUM50VD Outdoor unit SRC50ZIX-S
Power source 220-240V
~
50Hz / 220V
~
60Hz
Operation data Cooling Heating
Nominal capacity kW 5.0 [ 2.2 (Min.)
~
5.6 (Max.)] 5.4 [ 2.5 (Min.)
~
6.3 (Max.)]
Power consumption kW 1.52 1.41
Running current A 6.7 / 7.1 6.3 / 6.5
Power factor % 98 98
Inrush current A 5 < Max.running current 14 >
Sound Pressure Level dB(A) P-Hi : 35 Hi : 34 Me : 31 Lo : 28 47
Exterior dimensions
Height x Width x Depth
mm 299 × 750 × 635 640 × 800 × 290
Exterior appearance
(
Munsell color)
—
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg 34 43
Refrigerant equipment
Compressor type & Q'ty
— 5CS130XG04 × 1
Starting method — Direct line start
Refrigerant oil — 0.48 RB68A
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Centrifugal fan × 2 Propeller fan × 1
Motor <Starting method> W 60 < Direct line start > 45 < Direct line start >
Air flow (Standard) CMM P-Hi : 14 Hi : 13 Me : 12 Lo : 11 40
Available static pressure Pa 85 / 90 (at 14 CMM) —
Outdoor air intake Possible —
Air filter, Q'ty Procure locally —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — —
Remote controller wired : RC-E4 (option) wireless : RCN-KIT3-E (option)
Room temperature control Thermostat by electronics —
Safety equipment
Internal thermostat for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line : I/U
φ
6.35 (1/4") Pipe
φ
6.35 (1/4") × 0.8 O/U
φ
6.35 (1/4")
Gas line :
φ
12.7 (1/2")
φ
12.7 (1/2") × 0.8
φ
12.7 (1/2")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length
Max.30m
Vertical height difference between
outdoor unit and indoor unit
Max.20m (Outdoor unit is higher)
1.See page 154
Max.20m (Outdoor unit is lower)
Refrigerant Quantity R410A 1.4kg in outdoor unit (incl. the amount for the piping of : 15m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size
φ
20 × 5pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Drain hose Drain elbow, Drain hole grommet
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Extemal static pressure of indoor unit
Operation DB WB DB WB Pa
Cooling 27˚C 19˚C 35˚C 24˚C
60
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Initial static pressure values of optional air filter "UM-FL1E" are 5Pa.
(6) When wireless remote controlier is used, fan is 3 speed setting (Hi-Me-Lo) only.
(4) Duct connected - Low/Middle static pressure type (FDUM)
(a) Single type
PJR002Z389
a
PJR002Z389
a
