'21 • KX-T-380
1
After elapsing 3 minutes
from power OFF
Parts Ref.No. Tightening torque
IGBT IC2 2.5 - 2.7 N・m
Inverter PCB TB1-13 2.5
- 2.7 N・m
Inverter PCB
After elapsing 3 minutes
from power OFF
*Presence and shape of electric component
may vary according to model.
CNC3
TB7
Parts No.
TB12
TB6
TB13
TB4
CNIP
CNR2
CNR1
TB5
TB8
TB9
TB10
CNR3
T11
TB11
T12
JSW10
CNI2
TB1 / T1
TB2 / T2
TB3 / T3
Niplocker
attach point
Front side
Fig.1 Parts arrangement
Fig.2 PCB mounting position and voltage measurement points
Table Recommended tightening torque
IC2
Spacer
attach point
Back side
1.
*Presence and shape of electric
component may vary according
to model.
Be sure that the voltage (DC) is under 30 V
Voltage (DC) measurement points
: TB6 and TB7 on the Inverter PCB
Never plug connectors
in half inserted
LED1
(Yellow)
