Chapter 12 MAIN SPECIFICATIONS
Main specifications
Note: This specifications above are for standard engines. Each item may vary according to engine variation.
Table 12-1 Main specifications
Engine model L2E L3C L3E
Type 4-cycle, water-cooled, vertical, diesel
Number of cylinders, arrange-
ment
2-in-line 3-in-line
Bore×Stroke (mm [in.]) 76 × 70 [2.99 × 2.76] 70 × 70 [2.76 × 2.76] 76 × 70 [2.99 × 2.76]
Total displacement (Liter [cu.in.]) 0.635 [38.7] 0.808 [49.3] 0.952 [58.1]
Combustion type Swirl chamber type
Compression ratio 23 : 1
Firing order 1 - 2 1 - 3 - 2
Rotation direction Counterclockwise as viewed from flywheel
Dimensions
(L × W × H (mm) [in.])
417 × 418 × 500
[16.4 × 16.5 × 19.7]
505 × 418 × 500
[19.9 × 16.5 × 19.7]
Dry weight (kg [lbs]) 61 [134] 75 [165]
Fuel JIS K2204, Diesel oil or its equivalent (ASTM D975, etc.).
Fuel injection pump DENSO CORPORATION ND-PER type
Fuel filter Cartridge-type paper element or changing cock-type paper element
Fuel injection nozzle Throttle type
Initial fuel injection pressure
(MPa {kgf/cm²} [psi])
13.7 {140} [1991]
Lubricating system Forced circulation type
Lubrication oil Class CF or CH-4 oil (API service classification)
Engine oil capacity
(liter [U.S.gallon])
Including filter :
approx. 2.5 [0.66]
(Oil pan high/ low :
approx. 2.0 / 1.3 [0.53 / 0.34])
Standard oil pan
Including filter : approx. 3.6 [0.95]
(Oil pan high/ low : approx. 3.1 / 1.8 [0.82 / 0.48])
Deep oil pan
Including filter : approx. 4.7 [1.24]
(Oil pan high / low : approx. 4.2 / 3.0 [1.11 / 0.79])
Oil filter Cartridge-type paper element
Cooling system Force water cooling
Cooling water capacity
(liter [U.S.gallon])
Approx. 1.2 [0.32]
(in engine only)
Approx. 1.8 [0.48] (in engine only)
Starting system Electrical start
Starter 12 V - 1.2 kW 12 V - 1.7 kW
Alternator 12 V - 40 A
