Mitsubishi Heavy Industries SCM50ZS-S1 User Manual

-
121
-
'18 • SCM-T-251
(c) Indoor unit except SRK
ZSX and SKM ZSP type
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
2
units
3
units
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
2
units
3
units
<Cooling>
20 2.0 - - 1.8 2.0 2.7 500 580 900 2.7 2.6 2.5
25 2.5 - - 1.8 2.5 3.2 500 760 1070 3.6 3.4 3.3
35 3.5 - - 1.8 3.5 3.7 500 1140 1230 5.3 5.1 4.9
50 5.0 - - 1.8 5.0 5.3 500 1790 2000 8.3 7.9 7.6
20 + 20 2.00 2.00 - 3.0 4.0 5.6 570 950 1800 4.4 4.2 4.1
20 + 25 1.91 2.39 - 3.0 4.3 5.8 570 1110 1980 5.2 4.9 4.7
20 + 35 1.82 3.18 - 3.0 5.0 6.1 570 1490 2070 6.9 6.6 6.3
20 + 50 1.71 4.29 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
25 + 25 2.35 2.35 - 3.0 4.7 6.1 570 1320 2070 6.1 5.9 5.6
25 + 35 2.21 3.09 - 3.0 5.3 6.3 570 1660 2150 7.7 7.4 7.1
25 + 50 2.00 4.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 35 3.00 3.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 50 2.47 3.53 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
20 + 20 + 20 1.67 1.67 1.67 3.4 5.0 6.9 690 1120 2150 5.2 5.0 4.8
20 + 20 + 25 1.60 1.60 2.00 3.4 5.2 6.9 690 1200 2150 5.6 5.3 5.1
20 + 20 + 35 1.49 1.49 2.61 3.4 5.6 6.9 690 1370 2150 6.4 6.1 5.8
20 + 25 + 25 1.54 1.93 1.93 3.4 5.4 6.9 690 1300 2150 6.0 5.8 5.5
20 + 25 + 35 1.45 1.81 2.54 3.4 5.8 6.9 690 1470 2150 6.8 6.5 6.3
25 + 25 + 25 1.87 1.87 1.87 3.4 5.6 6.9 690 1370 2150 6.4 6.1 5.8
25 + 25 + 35 1.76 1.76 2.47 3.4 6.0 6.9 690 1540 2150 7.1 6.8 6.5
<Heating>
20 3.0 - - 1.4 3.0 3.5 480 1020 1100 4.8 4.6 4.4
25 3.4 - - 1.4 3.4 4.0 480 1180 1240 5.6 5.3 5.1
35 4.5 - - 1.4 4.5 4.8 480 1470 1490 6.9 6.6 6.3
50 5.8 - - 1.4 5.8 6.0 480 1910 2260 8.8 8.4 8.0
20 + 20 2.95 2.95 - 2.0 5.9 7.0 540 1510 2580 7.0 6.7 6.4
20 + 25 2.67
3.33 - 2.0 6.0 7.0 540 1560 2580 7.2 6.9 6.6
20 + 35 2.29 4.01 - 2.0 6.3 7.0 540
1650 2580 7.7 7.3 7.0
20 + 50 1.89 4.71 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
25 + 25 3.05 3.05 - 2.0 6.1 7.0 540 1590 2580 7.4 7.1 6.8
25 + 35 2.67 3.73 - 2.0 6.4 7.0 540 1680 2580 7.8 7.5 7.1
25 + 50 2.20 4.40 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 35 3.30 3.30 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 50 2.72 3.88 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
20 + 20 + 20 2.00 2.00 2.00 3.0 6.0 7.3 600 1340 2580 6.2 5.9 5.7
20 + 20 + 25 1.91 1.91 2.38 3.0 6.2 7.3 600 1430 2580 6.6 6.3 6.1
20 + 20 + 35 1.76 1.76 3.08 3.0 6.6 7.3 600 1600 2580 7.4 7.1 6.8
20 + 25 + 25 1.83 2.29 2.29 3.0 6.4 7.3 600 1510 2580 7.0 6.7 6.4
20 + 25 + 35 1.70 2.13 2.98 3.0 6.8 7.3 600 1660 2580 7.7 7.4 7.1
25 + 25 + 25 2.20 2.20 2.20 3.0 6.6 7.3 600 1600 2580 7.4 7.1 6.8
25 + 25 + 35 2.06 2.06 2.88 3.0 7.0 7.3 600 1730 2580 8.0 7.7 7.3
