29
-
2.4 Piping system
Model SCM40ZF-S
Outdoor unit
Indoor unit
Sensor
Sensor
(Th
I
-R
2
)
(Th
I
-R
1
)
(Th
I
-A)
Sensor
Sensor
(Th
O
-C)
Check joint
Check joint
Check joint
Sensor
(Th
O
-D)
Sensor
(Th
O
-A)
Sensor
(Th
O
-R)
Heat exchanger
Heat exchanger
Liquid line
Gas line
(ø6.35)
(ø6.35)
(ø9.52)
(ø9.52)
Strainer
Compressor
Muffler
4 way valve
Service valve
(Liquid)
Capillary tube
Capillary tube
Electric
expansion valve
EEVA
EEVB
Cooling cycle
Heating cycle
Service valve
(Gas)
Accumlator
Accumlator
Discharge
Suction
