'09•SRK-DB-087D
(5)ޓFlap and louver control
(a) Flap
(b) Louver
(c) Swing
1)
2)
(c) Memory flap (Flap or Louver stopped)
(d) When not operating
COOL , DRY, FAN
Remote controller
display
HEAT
Approx. 10°
Approx. 25°
Approx. 25°
Approx. 40°
Approx. 40°
Approx. 50° Approx. 70°
(Swing)
(Flap stopped)
Approx. 50°
Approx. 60°
Approx. 60°
Angle of Flap from Horizontal
Center installation
Remote controller
display
Right end installation
Left end installation
Angle of Louver
Left Approx. 50°
Left Approx. 50°
Left Approx. 20°
Left Approx. 45°
Center
Left Approx. 30°
Right Approx. 20°
Center
Right Approx. 50°
Right Approx. 20°
Left Approx. 20°
Center
Right Approx. 30° Right Approx. 45° Right Approx. 50°
(Louver stopped)
(Swing) (Spot) (Wide)
In HEAT operation In COOL, DRY, FAN operation
Approx. 25°
Approx. 70°
Approx.
10°
Approx. 60°
To Next Page
