Mitsubishi Ecodan User Manual

1-zone temperature control
1
2-zone temperature control
3
7
5
2
4
6
8
9
10
11
1
12
1
5
4
3
6
2
13
14
15
2
13
14
15
7
5
4
3
6
1
8
9
10
11
12
1-zone temperature control with boiler
2-zone temperature control with boiler
1. Zone1 heat emitters (e.g. radiator, fan coil unit) (eld supply)
2. Mixing tank (eld supply)
3. Zone1 ow water temp. thermistor (THW6)
4. Zone1 return water temp. thermistor (THW7)
5. Zone1 water circulation pump (eld supply)
6. Zone1 ow switch (eld supply) *
7. Motorized mixing valve (eld supply)
8. Zone2 ow water temp. thermistor (THW8)
9. Zone2 return water temp. thermistor (THW9)
10. Zone2 water circulation pump (eld supply)
11. Zone2 ow switch (eld supply) *
12. Zone2 heat emitters (e.g. underoor heating) (eld supply)
13. Boiler ow water temp. thermistor (THWB1)
14. Boiler return water temp. thermistor (THWB2)
15. Boiler
Local system
1
2
3
5
6
4
Zone1
Zone1
Zone2
Zone1
Zone1
Zone1
Zone2
* Flow switch specications: DC13 V / 0.1 mA / Both normally-open and normally-closed types can be used. (Set Dip switch 3 to select the logics. Refer to “ 5.1 Dip
switch function”.)
Optional part : PAC-TH011-E
Optional part : PAC-TH011-E
Optional part : PAC-TH011HT-E
