10 Edit function in data setting
10.6 Initializing data
97
FX Configurator-FP
Operation Manual
1
Introduction
2
Install Uninstall Start&Exit
3
Window and Operation Config
4
Creating Files
5
Data set
6
Setting The Connection
7
Data flow And Procedure
8
Debug In the Positioning
9
Print
10
Edit Function In data
10.6 Initializing data
Initializing the positioning parameters, servo parameters and table information along each axis.
1 Select [Tool]  [Initialize data].
[Initialize data] dialog box appears.
2 Set the data to initialize.
Item Description
Positioning Parameters
Initializes the positioning parameters along the ticked axis
•X-axis
•Y-axis
Servo Parameters
Initializes the servo parameters along the ticked axis
•X-axis
•Y-axis
Table Information
Initializes the table information along the ticked axis
•X-axis
•Y-axis
• XY-axis
