FX Configurator-FP
Operation Manual
Revised History
Revised History
Date Revision Description
12/2005 A First Edition
1/2007 B Added items for Ver.1.10
Supports FX
3U-20SSC-H (Ver.1.10)
• Ring counter setting was added.
• Servo parameter transfer mode selection was added.
• Mode selection added to the Interrupt stop at 1-step speed
• Reciprocal movement instruction was added.
• Add the following function of MPG operation.
- MPG input selection
- MPG response
• System Reset was added.
• Servo parameter update stop was added.
New features
• Insert row / Delete row was added.
Clerical error correction
7/2007 C Added items for Ver.1.20
Supports FX
3U-20SSC-H (Ver.1.20)
• Sudden stop deceleration time was added.
• Sudden stop interpolation time constant was added.
• Sudden stop selection was added.
• Interpolation gear ratio selection was added.
• Positioning completion signal output waiting time was added.
• Positioning parameter change completion flag was added.
• Real current value monitor was added.
- Real current address
• Received target value monitor was added.
- Received target address
- Received target speed
1/2008 D Added items for Ver.1.30
•Microsoft
Windows Vista
added to the applicable Operating Systems of the
personal computer.
• Connection via GOT1000 (GT15, GT11) series transparent mode was added.
9/2009 E Added items for Ver.1.40
• Servo startup ON/OFF selection was added.
• In interrupt operation, current address storing and display was added.
• Acceleration and deceleration time 2 setting is was added.
1/2010 F Setting range for positioning parameter (Ring counter upper limit value) changed.
2/2011 G Added items for Ver.1.50
Supports FX
3U-20SSC-H (Ver.1.40)
• Servo parameter was added.
Microsoft
Windows
7 32 bit version added to the applicable Operating System of the
personal computer.
7/2012 H Added items for Ver.1.50
Microsoft
Windows
7 64 bit version added to the applicable Operating System of the
personal computer.
Added items for Ver.1.60
MELSERVO-J4 for MELSERVO series was added.
2/2014 J Added items for Ver.1.70
•Microsoft
Windows
8 and Microsoft
Windows
8.1 were added to the applicable
Operating System of the personal computer.
• The start from GX Works2 was added to the starting method.
• Ethernet directly connect was added.
4/2015 K • A part of the cover design is changed.
9/2016 L
•Microsoft
Windows
10 added to the applicable Operating System of the personal
computer.
11/2016 M • A part of the cover design is changed.
