20
2 Replacement from FX3U to FX5U
2.3 Selection of Substitute Models
Recommended Substitute Models for Extension Devices
The following list shows the extension devices that will be necessary to replace simultaneously when replacing the CPU
module from FX3U to FX5U.
For products without a substitute model of the same function, check the contents described in the Special notes and please
consider system reconfiguration.
■List of extension devices required to replace when replacing the CPU module from FX3U to
FX5U
CPU module FX3U-64MT/DS FX5U-64MT/DS
FX3U-64MT/DSS FX5U-64MT/DSS
FX3U-80MR/DS FX5U-80MR/DS
FX3U-80MT/DS FX5U-80MT/DS
FX3U-80MT/DSS FX5U-80MT/DSS
FX3U-32MR/UA1 No recommended substitute models
FX3U-64MR/UA1 No recommended substitute models
Extension device Recommended Substitute Models Special notes
Device name Model name Model name
Extension I/O FX2N-8ER FX5-16ER/ES The number of I/O increases in the recommended
substitute models.
FX2N-8ER-ES/UL FX5-16ER/ES The number of I/O increases in the recommended
substitute models.
FX2N-8EX FX5-8EX/ES
FX2N-8EX-ES/UL FX5-8EX/ES
FX2N-8EX-UA1/UL No recommended substitute models
FX2N-16EX FX5-16EX/ES
FX2N-16EX-ES/UL FX5-16EX/ES
FX2N-16EX-C FX5-CNV-IF+FX5-C16EX/D Only a connector type module can be connected
after (on the right side of) FX5-CNV-IF.
FX2N-16EXL-C No recommended substitute models
FX2N-8EYR FX5-8EYR/ES
FX2N-8EYR-ES/UL FX5-8EYR/ES
FX2N-8EYR-S-ES/UL No recommended substitute models
FX2N-8EYT FX5-8EYT/ES
FX2N-8EYT-ESS/UL FX5-8EYT/ESS
FX2N-8EYT-H No recommended substitute models
FX2N-16EYR FX5-16EYR/ES
FX2N-16EYR-ES/UL FX5-16EYR/ES
FX2N-16EYT FX5-16EYT/ES
FX2N-16EYT-ESS/UL FX5-16EYT/ESS
FX2N-16EYT-C FX5-CNV-IF+FX5-C16EYT/D Only a connector type module can be connected
after (on the right side of) FX5-CNV-IF.
FX2N-16EYS No recommended substitute models
FX2N-32ER FX5-32ER/ES
FX2N-32ER-ES/UL FX5-32ER/ES
FX2N-32ET FX5-32ET/ES
FX2N-32ET-ESS/UL FX5-32ET/ESS
FX2N-32ES No recommended substitute models
FX2N-48ER FX5-32ER/ES+FX5-16ER/ES
FX2N-48ER-ES/UL FX5-32ER/ES+FX5-16ER/ES
FX2N-48ET FX5-32ET/ES+FX5-16ET/ES
FX2N-48ET-ESS/UL FX5-32ET/ESS+FX5-16ET/ESS
FX3U Series Recommended Substitute Models Special notes
Device name Model name Model name
