48
4 Conversion of the Projects
4.3 Precautions when Replacing the Parameters
Precautions for Device Replacement
Precautions for Device Replacement
Index modification of the S device (state) cannot be made on the MELSEC iQ-F. Replace as follows.
• When the S device without state management has its index modified, replace to M device to use.
• When the S device used for state management has its index modified and used for the ZRST instructions, program the
ZRST instructions for each batch-clear pattern.
For GX Works3 whose version is earlier than 1.030G, the assigned device of the global label cannot be read out.
• Information of the assigned device in GX Works2 is input in the comment field. Refer to the comment field to assign the
device again.
• When special M and special D have been assigned, they will be replaced and assigned to SM and SD.
If S device is set to the device memory data or device initial data created using GX Works2, it will be deleted.
If there is a device that is not supported by the MELSEC iQ-F Series in the program created using GX Works2, the device will
be changed to SM4095/SD4095.
The default value is set to the parameter setting of device points.
SM/SD Device Replacement
Devices, M8000 and later and D8000 and later of FX3U/FX3UC, will be changed to devices, SM8000 and later and SD8000
and later. However, some devices may be changed depending on the version of GX Works3. For details, refer to the following.
4.3 Precautions when Replacing the Parameters
When converting projects of the FX3 Series to MELSEC iQ-F projects, the setting data of the parameters (PLC parameter and
network parameter) and special module (intelligent function module) will be deleted. Therefore, it is necessary to reset the
data with GX Works3.
Also, GX Works3 does not support the following parameters of FX3 Series, so it is necessary to set with GX Works3 again.
• Network parameter (CC-Link)
• Intelligent function module parameter (AnyWireASLINK)
FX3U/
FX3UC
After replacing to MELSEC iQ-F FX3U/
FX3UC
After replacing to MELSEC iQ-F
GX Works3 version
1.032J and earlier
GX Works3 version
1.035M and later
GX Works3 version
1.032J and earlier
GX Works3 version
1.035M and later
M8004 SM8004 SM0 M8240 SM8240 SM4585
M8009 SM8009 SM0 M8241 SM8241 SM4580
M8061 SM8061 SM0 M8242 SM8242 SM4582
M8064 SM8064 SM0 M8243 SM8243 SM4584
M8065 SM8065 SM0 M8244 SM8244 SM4580
M8066 SM8066 SM0 M8245 SM8245 SM4582
M8091 SM8091 SM701 M8318 SM8318 SM0
M8131 SM8131 SM5001 M8489 SM8489 SM0
M8133 SM8133 SM5001 D8004 SD8004 SD0
M8138 SM8138 SM5001 D8009 SD8009 SD0
M8139 SM8139 SM5000 D8061 SD8061 SD0
M8165 SM8165 SM703 D8064 SD8064 SD0
M8235 SM8235 SM4580 D8065 SD8065 SD0
M8236 SM8236 SM4581 D8066 SD8066 SD0
M8237 SM8237 SM4582 D8101 SD8101 SD8001
M8238 SM8238 SM4583 D8166 SD8166 SD83
M8239 SM8239 SM4584 D8489 SD8489 SD0
