EN-7
ENGLISH
Projector exterior view
1. External control panel
(See "Projector" on page 8 for details.)
2. Vent (heated air exhaust)
3. Quick-release button
4. Lens cover
5. Focus ring and Zoom ring
6. Front IR remote sensor
7. Projection lens
8. AC power cord inlet
9. Video input socket
10. RGB (PC)/Component Video (YPbPr/ YCbCr) signal
input socket
11. S-Video input socket
12. RS-232 control port
13. Kensington Lock
14. Quick-release foot
15. Lamp cover
16. Rear adjuster foot
Kensington Lock
This projector has a Kensington Security Standard connector
for use with Kensington MicroSaver Security System.
Refer to the information that came with the Kensington System
for instructions on how to use it to secure the projector. Please
contact Kensington Technology Group below.
Kensington Technology Group
2855 Campus Drive
San Mateo, CA 94403, U.S.A.
Phone: +1- (650)572-2700 Fax: +1- (650)572-9675
