Montech MonTurn TB40 User Manual

Assembly instructions BA-100155
Control unit MonTurn
22
WARNING!
The power supply of the control unit may only be switched on when all connecting cables
are connected and connected to the TB40 conveyor belt.
5.4.2.3 Connecting cable signal TB40 <–> MonTurn
5.4.3 Turn on and turn off behavior
Figure 10: Turn on and turn off behavior
Figure 9: Picture signal cable
Connection MonTurn
Connection TB40
