42 October 14, 2005 6809495A75-O
Troubleshooting L6
Exploded View Parts List
To order parts please use the following link:
https://accesssecure.mot.com
(Password is required)
Table 5. Parts list
Item
Motorola Part
Number
Description Item
Motorola Part
Number
Description
1 1571265A01 Front housing 20 0171373A01 Chassis assembly V280
2 1371263A01 Logo medallion 21 7271331A01 LCD display 128x160
3 3571266A01 Mesh, front housing 22 0771258A01 Metal display bracket
4 1170314A20 Earpiece speaker adhesive 23 6171259A01 Display lens
5 8571267A01 Bluetooth antenna 24 9471281A01 Camera module (L6 only)
6 0170298Z22 Earpiece speaker assembly 25 3771324A01 Camera grommet (L6 only)
7 7571250A01 Keypad English 26 AAUG1858AA Main PCB assembly
8 3070338B01 Coaxial cable 27 2671252A01 Shield cover
9 4071256A01 Metal dome array 28 7571369A04 PCB cover poron pad
10 3571329A05 Microphone mesh 29 5971287A01 Vibrator Ass’y w/grommet
11 AALG4329AA Keypad PCB assembly 30 3371408A01 PCB cover label
12 8571365A01 Main antenna Euro
Main antenna US
31 7571369A16 Main flex poron pad
13 0771366A01 Antenna support euro
Antenna support US
32 6171261A01 Camera lens (L6 only)
14 3571270A01 Polyphonic speaker mesh 33 0170298Z17 Top rear cover assembly
15 0387347Y01 Screw x6 34 SNN5779A
SNN5768A
Battery SC4
Battery SC5
16 327123A04 Earpiece speaker assembly 35 3771278A01 RF connector grommet
17 5088317Y01 Polyphonic Speaker 36 1571277A01 Rear bottom cover
18 3271233A06 Polyphonic speaker damper 37 1571372A01
1571249A01
Battery door L6 (SC4)
Battery door L6 (SC5)
19 3271271A01 Acoustic gasket
E
There is a danger of explosion if the Lithium ion battery pack is replaced incorrectly.
Replace only with the same type of battery or equivalent as recommended by the
battery manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
