Getting Started 11
ENGLISH
2. If the parent unit is turned ON, when the adapter is plugged in, the battery
icon in the screen’s top right corner will show that the battery is charging
by cycling the internal segments, The Blue LED in the top left corner lights
up to indicate the adapter is plugged in.
2.4 Registration (Pairing)
The Baby monitor is pre-registered to your Parent Unit. You do not need to
register it again unless the Baby Unit loses its link with the Parent Unit. To re-
register your Baby Unit, or register a new Baby Unit, follow the procedure below:
1. Press the
M Menu button of the parent unit and the menu bar will pop up.
2. Press the
< LEFT button or > RIGHT button until C is highlighted, and
the /
+// menu will pop up.
3. Press the
+ UP button or - DOWN button to select +, and press the OK
button to confirm.
4.
C 1 / C 2 / C 3 / C 4 will pop up, press the + UP button or - DOWN
button to select the desired CAM and press the OK button to start
searching for a camera unit. The green audio level LED will flash rapidly
while searching.
5. Press and hold the PAIR button underneath the baby unit until the parent
unit finds the camera, beeps and the video from the camera appears.
NOTE
If a particular Baby Unit was registered previously, registering this current Baby
Unit again will overwrite the old registration.

Motorola MBP43 Specifications

General

Maximum range	179 m
Volume control	Digital
Smartphone support	-
Number of lullabies	5
Brightness adjustment	Yes
Number of brightness levels	8
Product color	White
LED type	IR
Sensor type	CMOS
Digital zoom	2 x
Fixed aperture	2.8 mm
Fixed focal length	2.5 mm
Display diagonal	3.5 \
Display number of colors	16.78 million colors
AC input voltage	100-240 V
Power source type	AC, Battery
AC input frequency	50 - 60 Hz
Battery technology	Nickel-Metal Hydride (NiMH)
Interface	RF
Frequency band	2.4 - 2.48 GHz
