MD7161 User Guide
59
Technical Specifications
FREQUENCY CONTROL
Crystal Controlled
PLL synthesizer
TRANSMIT FREQUENCY
Base: 5744.736 - 5825.952 MHz
Handset: 2401.056 - 2482.272 MHz
RECEIVE FREQUENCY
Base: 2401.056 - 2482.272 MHz
Handset: 5744.736 - 5825.952 MHz
CHANNELS
95 channels
NOMINAL EFFECTIVE RANGE
Maximum power allowed by FCC and IC. Actual operating range
may vary according to environmental conditions at the time of
use.
WEIGHT
Handset: 102 g (excluding batteries)
Base: 141 g
Charge-only base: 55 g
POWER REQUIREMENTS
Handset: 3.6 V 600 mAh NiMH
Base: 8 V DC @ 650 mA
Charge-only base: 8 V DC @ 200 mA
MEMORY
Phonebook: 50 memory locations; up to 32 digits for
number, 16 characters for name, per location
CID: 50 records
SIZE
Handset: 136 mm x 47 mm x 29.5 mm (including
antenna)
Base: 110 mm x 108.40 mm x 55.66 mm
Charge-only base: 80 mm x 78 mm x 54 mm
SPECIFICATIONS ARE TYPICAL AND MAY
CHANGE WITHOUT NOTICE
