FREQUENCY AND CODE
English
68
RM UHF Frequencies (cont.)
Frequency #
Frequency
(MHz)
Bandwidth Frequency #
Frequency
(MHz)
Bandwidth
73 452.5375 12.5 kHz 82 456.4375 12.5 kHz
74 452.4125 12.5 kHz 83 456.5375 12.5 kHz
75 452.5125 12.5 kHz 84 456.6375 12.5 kHz
76 452.7625 12.5 kHz 85 457.3125 12.5 kHz
77 452.8625 12.5 kHz 86 457.4125 12.5 kHz
78 456.1875 12.5 kHz 87 457.5125 12.5 kHz
79 456.2375 12.5 kHz 88 457.7625 12.5 kHz
80 456.2875 12.5 kHz 89 457.8625 12.5 kHz
81 456.3375 12.5 kHz
Notes:
•
When referring to XTN radios, note that
frequencies from # 57 to # 89 are 33 new
additional frequencies
