MSI B365M PLUS User Manual

1
<󸙗󳽙 1> Inhalt
Inhalt
Sicherheitshinweis .......................................................................................... 2
Spezifikationen ................................................................................................ 3
Rückseite E/A ..................................................................................................6
B365M PRO-VH/ B365M PLUS............................................................................6
B365M PRO-VD ...................................................................................................6
B365M WIND .......................................................................................................6
LAN Port LED Zustandstabelle ...........................................................................7
Übersicht der Komponenten ........................................................................... 7
CPU Sockel..........................................................................................................8
DIMM-Steckplätze ..............................................................................................9
PCI_E1~3: PCIe Erweiterungssteckplätze .........................................................9
JFP1, JFP2: Frontpanel-Anschlüsse ................................................................ 10
SATA1~6: SATA 6Gb/s Anschlüsse ...................................................................10
M2_1: M.2 Steckplatz (Key M) (B365M PRO-VD, B365M PRO-VH, B365M
PLUS) ................................................................................................................11
ATX_PWR1, CPU_PWR1: Stromanschlüsse .....................................................11
JUSB1, JUSB2: USB 2.0 Anschlüsse ................................................................12
JUSB3: USB 3.1 Gen1 Anschluss......................................................................12
JAUD1: Audioanschluss des Frontpanels ........................................................13
JCOM1: Serieller Anschluss .............................................................................13
JTPM1: TPM Anschluss ....................................................................................13
EZ Debug LED ...................................................................................................13
CPU_FAN1, SYS_FAN1: Stromanschlüsse für Lüfter ......................................14
JCI1: Gehäusekontaktanschluss ......................................................................15
JBAT1: Clear CMOS Steckbrücke (Reset BIOS)................................................15
BIOS-Setup ....................................................................................................16
Öffnen des BIOS Setups ....................................................................................16
Reset des BIOS .................................................................................................17
Aktualisierung des BIOS ...................................................................................17
Installation von OS, Treibern und Utilities .................................................... 18
Installation von Windows
®
10 ...........................................................................18
Installation von Treibern ...................................................................................18
Installation von Utilities ....................................................................................19
Danke, dass Sie sich für das MSI
®
B365M PRO-VD/ B365M
PRO-VH/ B365M WIND/ B365M PLUS Motherboard entsch-
ieden haben. Dieses Handbuch gibt informationen über
Motherboard-Layout, Komponentenübersicht, BIOS-Setup
und Softwareinstallation.

MSI B365M PLUS Specifications

General

Form Factor	Micro ATX
Chipset	Intel B365
Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64 GB
Memory Speed	DDR4 2666/2400/2133 MHz
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA 6Gb/s, 1 x M.2
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
