MSI H110M PRO-D User Manual

15



There is CMOS memory onboard that is external powered from a battery located on
the motherboard to save system configuration data. If you want to clear the system
configuration, set the jumpers to clear the CMOS memory.
Keep Data
(default)
Clear CMOS/
Reset BIOS

1. Power off the computer and unplug the power cord
2. Use a jumper cap to short  for about 5-10 seconds.
3. Remove the jumper cap from .
4. Plug the power cord and power on the computer.

These LEDs indicate the status of the motherboard.
 - indicates CPU is not detected or fail.
 - indicates DRAM is not detected or fail.
 - indicates GPU is not detected or fail.

MSI H110M PRO-D Specifications

General

Form Factor	Micro ATX
Chipset	Intel H110
Socket	LGA 1151
Memory Slots	2 x DIMM
Maximum Memory	32 GB
Memory Speed	2133 MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
Storage Interface	4 x SATA 6Gb/s
Video Outputs	1 x DVI-D, 1 x VGA
USB Ports	4 x USB 3.1 Gen1, 6 x USB 2.0
Audio	Realtek ALC887
LAN	Realtek RTL8111H Gigabit LAN
