A-14
MS-6712 ATX Mainboard
Testing the Connected Speakers
MSI Reminds You...
6 speakers appear on the “Speaker Test” window only when
you select “6-Channel Mode” in the “No. of Speakers” column.
If you select “4-Channel Mode”, only 4 speakers appear on the
window.
To ensure that 4- or 6-channel audio operation works properly, you may
need to test each connected speaker to make sure every speaker work properly.
If any speaker fails to sound, then check whether the cable is inserted firmly
to the connector or replace the bad speakers with good ones.
Testing Each Speaker
1. Click the audio icon from the window tray at the lower-right corner of
the screen.
2. Click the Speaker Test tab.
3. The following window appears. Select the speaker which you want to test
by clicking it.
Subwoofer
Front Right
Rear Right
Center
Front Left
Rear Left
To Next Page
