MSI MEG X299 CREATION User Manual

15
Specifications
Specifications
CPU
Supports Intel
®
Core™ X-Series Processor Family for
LGA2066 Socket
Chipset Intel
®
X299 Chipset
Memory
y 8x DDR4 memory slots
y Quad channel memory architecture with the CPU that
supports up to 4-channels DDR4**
 Quad channel support up to 128GB
 X-series processor support DDR4 4200(OC)/ 4100(OC)/
4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/
3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/
2800(OC)/ 2666/ 2400/ 2133 MHz*
y Dual channel memory architecture with the CPU that
supports up to 2-channels DDR4**
 Dual channel support up to 64GB
 X-series processor support DDR4 4133(OC)/ 4000(OC)/
3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/
3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/
2800(OC)/ 2666/ 2400/ 2133 MHz*
y Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
** Please refer the DIMM Slots section for more details.
Expansion Slot
y 4x PCIe 3.0 x16 slots
 Support x16/x0/x16/x8, x8/x8/x16/x8 mode with the
44-lane CPU.*
 Support x16/x0/x8/x4, x8/x8/x8/x4 mode with the 28-
lane CPU.*
 Support x8/x0/x4/x4 mode with the 16-lane CPU.*
y 1x PCIe 3.0 x1 slot
* Please refer to page 34 for PCIe 3.0 bandwidth table.
Multi-GPU
y Supports NVIDIA
®
SLI
™
Technology
y Supports AMD
®
CrossFire
™
Technology
LAN
y 1x Intel I219-V Gigabit LAN controller
y 1x Realtek RTL8125-CG 2.5G LAN controller
Wirsless LAN &
Bluetooth
®
Intel
®
Wireless-AC 9260
y Supports 802.11 a/b/g/n/ac, MU-MIMO Rx, 2.4GHz/ 5GHz
(160MHz) up to 1.73Gbps
y Supports Bluetooth
®
2.1, 2.1+EDR, 3.0,4.0, 5
Continued on next page

MSI MEG X299 CREATION Specifications

General

Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	4100, 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 4000, 4200 MHz
Processor socket	LGA 2066 (Socket R4)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ X-series
Supported processor sockets	LGA 2066
USB 2.0 connectors	2
ATX Power connector (24-pin)	Yes
Number of SATA II connectors	0
Number of SATA III connectors	8
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III, U.2
BIOS type	UEFI AMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	Intel® X299
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Windows operating systems supported	Windows 10
LAN controller	Realtek RTL8125-CG, Intel I219-V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
Parallel processing technology support	CrossFire, SLI
Cables included	SATA

Weight and Dimensions

Depth	272 mm
Width	305 mm
