CHAPTER 2
HARDW
ARE INST
ALLA
TION
2-14
IrDA Infrared Module Connector: J4
The mainboard provides one infrared (J4) connector for IR modules. This
connector is for optional wireless transmitting and receiving infrared module.
Y
ou should configure the setting through the BIOS setup to use the IR
function.
VCC
NC
IRRX
GND
IRTX
1
J4
17
19
