16
Specifications
Specifications
CPU
y Supports New Intel
®
Core™ i7 Processor Extreme Edition
for LGA2011-3 Socket
y Supports Intel
®
Turbo Boost Max Technology 3.0*
* This function will be supported depend on the CPU.
Chipset Intel
®
X99 Chipset
Memory
y 8x DDR4 memory slots, support up to 128GB*
Supports DDR4 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/
3000(OC)/ 2933(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400/ 2200(OC)/ 2133 MHz
y Quad channel memory architecture
y Supports Intel
®
Extreme Memory Profile (XMP)
* For the latest information about memory, please visit http://www.msi.com
Expansion Slots
y 4x PCIe 3.0 x16 slots*
Support x16/ x0/ x0/ x0, x16/ x16/ x0/ x0, x16/ x16/ x0/
x8, x8/ x16/ x8/ x8 with the CPU that supports 40 PCIe
lanes.
Support x16/ x0/ x0/ x0, x16/ x8/ x0/ x0, x8/ x8/ x8/ x0,
x8/ x8/ x8/ x4 with the CPU that supports 28 PCIe lanes.
y 2x PCIe 2.0 x1 slots
* PCI_E6 slot shares the bandwidth with U.2 port and M.2 PCIe 3.0 x4. Please
refer to page 32 for PCIe 3.0 bandwidth table.
Multi-GPU
y Supports 3-Way AMD
®
CrossFire
™
Technology
y Supports 3-Way NVIDIA
®
SLI
™
Technology
USB
y ASMedia
®
ASM1142 Chipset
1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) port on the
back panel
1x USB 3.1 Gen2 (Super Speed USB 10Gbps) Type-C port
on the back panel
y Intel
®
X99 Chipset
5x USB 3.1 Gen1 (SuperSpeed USB) ports (1 internal
Type-C port on the board, 4 ports available through the
internal USB connectors)
8x USB 2.0 (High-speed USB) ports (4 ports on the
back panel, 4 ports available through the internal USB
connectors)
y VIA VL805 Chipset
4x USB 3.1 Gen1 (SuperSpeed USB) ports on the back
panel
Continued on next page
