NAD T 747 User Manual

The T 747 is equipped with a data port in the rear panel where an optional
NAD IPD Dock for iPod (NAD IPD) can be plugged in. With the NAD IPD
linking the T 747 with your own iPod player, you can enjoy listening to your
favorite tracks and playlists as well as view applicable still image and video
playback.
You can control your iPod player using the assigned buttons in the T 747
front panel. And with the corresponding AVR 3 remote control function
keys, you can select the materials stored in your iPod for playback as well as
access many of its functions even from across the room. The optional NAD
IPD also charges your iPod player while it is connected to the T 747.
NOTES
• NADIPDDockforiPod(NADIPD)currentlyhastwoversions–theNAD
IPD and NAD IPD 2. These two NAD IPD models and later variants are
compatible with the T 747.
• NADIPDandiPodplayerarenotsuppliedwithyourT747.
• iPodplayerfunctions,featuresandplaybackcapabilitiesaccessible
through T 747 may vary depending on your iPod player model.
• WhenusingtheAVR3tocontroltheiPodfunctions,makesurethatthe
Device Selector is set to “MP”.
CONNECTING THE OPTIONAL “NAD IPD DOCK FOR iPod”
AND iPod PLAYER TO THE T 747
Make sure that all the devices are unplugged before making the
connections.
1 Connect the NAD IPD’s DATA PORT to the corresponding “MP DOCK”
data port of the T 747.
2 Connect also the NAD IPD’s S-video output to T 747’s S-VIDEO 4 input
and NAD IPD’s audio out to the T 747’s AUDIO 4 input (the default iPod
source allocation in the T 747).
3 Dock your iPod player into the NAD IPD.
4 After linking together your iPod player, NAD IPD and the T 747, you can
now plug them IN to their applicable power sources.
5 With your iPod player, NAD IPD and T 747 all at power ON state, toggle
front panel’s [SOURCE ] to select “iPod” source. The upper line of
the VFD will show “iPod Menu”.
iPod MENU OPTIONS
There are two menu options for iPod – iPod Menu and Simple Mode. At
“iPod Menu”, iPod navigation will be done and guided through the VFD of
the T 747. At “Simple Mode” everything will be guided through your iPod’s
own display screen as you would do in normal iPod use.
The following is the procedure to switch between “iPod Menu” and “Simple
Mode” options
1 Press and hold [MENU] button in the front panel or AVR 3 for about 3
seconds.
2 “iPod Menu” is selected when the upper line of the VFD shows “iPod
Menu” and the lower line of the VFD shows “Playlist”. “iPod Menu” is the
default menu option.
3 Press and hold [MENU] button again and the upper line of the VFD
shows “iPod” and the lower line of the VFD shows “Simple Mode”. You
are now at Simple Mode.
iPod MENU
At “iPod Menu” mode, there are several available menu options that are
similar to what you can nd in an iPod player. The OSD shows the following
iPod Menu options – Playlists, Artists, Albums, Songs, Podcasts, Genres,
Composers and Audiobook. Use [ ] to move up or down the iPod
menu selections. Navigate and select through these VFD “iPod Menu”
options as you would when operating your iPod player independently.
NOTE
At “iPod Menu”, your docked iPod player’s click wheel and controls will
not be operational. Your iPod player will show in its display the NAD
logo. Use the corresponding front panel or AVR 3 buttons to navigate
through the “iPod Menu” options.
SIMPLE MODE
At “Simple Mode”, refer to your docked iPod player’s own display screen
to navigate and make full use of its features. Use your docked iPod’s own
click wheel and controls or the corresponding front panel or AVR 3 buttons
to select through the available options as displayed in your iPod player’s
display screen.
CONTROL FEATURES
Use the following control buttons in navigating through the iPod menu
options. Since the AVR 3 will be the primary controller in most cases, we
will focus on remote-controlled operations. Note that for other NAD IPD
models (like NAD IPD 2) that have remote control, below controls have the
same function as those available in the NAD IPD model’s remote control.
DISP
During playback, toggle [DISP] key of AVR 3 to show in the VFD upper line
the following
• Current iPod playback mode (shue, repeat modes)
• Song title
• Artist Name
• Album title
If there is no information available, the display will show “No Song”, “No
Artist” or “No Album” as applicable.
Press [ ] to return to a previous option or menu selection. Press [ ] to
move forward an option or make a selection.
While at menu options or selection lists, toggle [ ] to go up or down
the options, lists or song titles. Press and hold [ ] to quickly scroll
through the song titles.
ENTER APPLICABLE ONLY AT SIMPLE MODE
Press [ENTER] to select an option or start playback.
[ ]
During playback or PAUSE mode, press and hold [ ] for fast
forward or backward scanning of current song. Press [ ] to skip forward
to the next song or [ ] to skip back to the previous song.
PAUSE   / PLAY  
Press PAUSE [ ] during playback to stop playback temporarily. Resume
play by pressing PAUSE [ ] again or PLAY [ ].
OPERATION
LISTENING TO YOUR iPod PLAYER
38
