NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 63
CP-01 Quick Reference Chart--SIA False Alarm Reduction
Feature Description
Programming Address
Location (for reference
only
Exit Delay. Minimum allowed programmable Exit Delay time is 45 seconds. Default is 60 seconds. If an attempt is made to
change the Exit Delay time to less than 45 seconds the time will be entered as 60 seconds. The maximum programmable
time is 255 seconds. The panel uses the existing programmable by zone feature "Entry/ Exit 1" to comply with CP-01. At least
one Entry/Exit zone must be programmed for each area. The existing programmable Entry and Exit delay times are also used.
The factory program sets the Exit Time Delay as 60 seconds and Entry Time Delay as 30 seconds.
0000
Enable SIA FAR Exit /Entry Limits. When this option is enabled, the panel will sound an audible egress sequence when
it is armed Away (with interior zones not bypassed). The keypad mini-sounder will beep rapidly during exit delay to indicate
exit urgency. If the panel is armed Stay (with interior zones bypassed) the keypad mini-sounder is silent and the exit time is
double the programmed time. Note: This feature affects the operation of "Zone ANDing" as follows: If this feature is enabled,
any Zone in a Group will only activate an alarm and send a report ONCE. After the Zone has reported, it will remain in the
Group and may still initiate the Zone ANDing sequence.
7953, Option 6 (see Note 1)
(7953 ·····6 ··)*
Enable Exit Delay Restart. This option allows for the following scenario before the end of the Exit Time: a violation of an
entry/exit zone, a restore, and a second violation of an entry/exit zone restarts the Exit Time. The panel does not allow the Exit
Time to be restarted more than once. The default setting for this option is enabled. Restart is event logged.
7953, Option 2 (see Note 1)
(7953 · 2 ······)*
Enable Bell on Exit Error. An Exit Error sequence is initiated if an entry/exit zone is violated at the expiration of the Exit Time.
7953, Option 3 (see Note 1)
(7953 ··3 ·····)*
Automatic Interior Bypass/Easy Exit. Convert from Away to Stay based on no egress through exit door …default is en-
abled.
The panel uses the existing programmable feature "Auto Interior Bypass". This feature is enabled in the factory program.
5326, Option 1
(5326 1 ·······)*
Report Exit Error/Recent Closing. A Recent Closing transmission is sent if an alarm occurs within two (2) minutes after the
expiration of the Exit Time. If the user number is available, it is included in the Recent Closing transmission.
7953, Option 4 (see Note 4)
(7953 ···4····)*
Entry Delay. Entry Delay time is 30 second minimum, default is 30 seconds. If an attempt is made to change the Entry Delay
time to less than 30 seconds the time will be entered as 30 seconds. The maximum programmable time is 255 seconds. The
panel uses the existing programmable by zone feature "Entry/ Exit 1" to comply with CP-01. At least one Entry/Exit zone must
be programmed for each area. The existing programmable Entry and Exit delay times are also used. The factory program
sets the Exit Time Delay as 60 seconds and Entry Time Delay as 30 seconds.
0001, 0002
Progress Annunciation. Entry urgency annunciation must be different than the alarm mini-sounder. Requires Keypad
Sounder on Alarm on all non-Fire zones. See the Zone Options tables in the programming instructions (WI1673) for
specific address locations.
Feature in EZ Programming
Disarm. The panel will silence the keypad entry delay tones and alarm annunciation on the first press of a keypad
digit for 2.5 seconds.
New Panel Operation
Select Burg Bell on Keyfob Arming. Normally the chirp on a keyfob arm/disarm is transmitted to the Burg Module
PGM1 Output. Selecting "Select Burg Bell on Keyfob Arming" causes the "Burg Bell" to chirp instead of the
"Burg Module PGM1 Output" upon remote arming. The panel uses the existing programmable feature "Burg PGM1
Chirp On Keyfob Arm/Disarm" (Address 5326, option 4). The feature is selected in the factory program.
5327, Option 7 (see Note 3)
(5327 ······7·)*
Enable SIA FAR Exit /Entry Limits. When this option is enabled, three time limits are enabled as per the SIA CP-01 stan-
dards: (1) If the Exit Delay time is programmed for less than 45 seconds, the enabled Exit Delay time will be set to 60 sec-
onds; (2) If the Entry Delay time is programmed for less than 30 seconds, the enabled Entry Delay time will be set to 30 sec-
onds; and (3) If an attempt is made to change the Abort Delay to less than 15 seconds or more than 45 seconds the
time will be entered as 30 seconds. (4) Enables Exit Delay sounder. (5) Doubles Exit Delay time when arming Stay due to
Silent Exit.
7953, Option 6 (see Note 1)
(7953 ·····6 ··)*
Abort Window Disarm. The panel will silence the keypad entry delay tones and alarm annunciation on the first press of a
keypad digit for 2.5 seconds. Disarming of the area within the Abort Delay period will cause a cancellation of the Central Sta-
tion alarm report.
New Panel/Keypad Feature
Abort Annunciation after Disarming. Default is enabled. If the panel is disarmed during Abort Delay, the keypad will enun-
ciate abort. "Alarm Cancelled" is displayed on the keypad display.
New Panel/Keypad Feature
Report Cancel Window. When the system is in alarm and the user disarms in an attempt to Cancel within a maximum of 7
minutes after abort timeout, a Cancel Report will be sent. If Cancel Report is enabled by entering a cancel time, Cancel will
enunciate on the keypad if the system is disarmed during the Cancel Window. The existing programmable option Report Can-
cel Window must be programmed for at least 5 minutes to comply with CP-01 (factory default is 7 minutes).
Address 8168
Duress Feature. The existing programmable option "Enable Global Ambush" must not be enabled. It is not enabled in the
factory program.
Pre-existing feature
(continued)
