NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Page 66 Installation Instructions, Volume 2
When the Gemini C-Series control panel leaves the factory, or when a "Cold Start" is performed, the following pro-
gramming is entered:
• Panel is programmed for Commercial Fire Only
• The GEMC-F8ZCPIM enabled
• All 8 zones are set as Fire zones and are programmed to activate the 4 NAC's. All 4 NAC's are Silence-able and
in the System Sensor Format (thus requiring System Sensor Synchronized Horn/Strobes be installed)
• All 4 NAC's are synchronized (not offset, as required for more than 4A total alarm current)
• The AUX Fire relay is programmed as a Trouble relay (relay is normally energized and is de-energized for any
Trouble)
• A pre-programmed Fire User Code of "1,2,3,4" is set
• Not programmed for Reporting
• Panel configured for one (1) GEMC-FK1 Fire keypad
• Standard Fire and Burglary time-outs entered.
NOTE: If the control panel is powered up without the GEMC-F8ZCPIM installed, zones 1-8 will indicate a Trouble at
the GEMC-FK1 Fire keypad.
FACTORY DEFAULT PROGRAM DESCRIPTION
