Caution Exercise caution when placing the sbRIO-9687 inside an enclosure.
Auxiliary cooling may be necessary to keep the device under the maximum ambient
temperature rating for the sbRIO-9687. Refer to the sbRIO-9687 Specifications for
more information about the maximum ambient temperature rating.
Caution The sbRIO-9687 is designed for non-hazardous live signals. You must
ensure that all signals connected to the sbRIO-9687 are isolated from hazardous live
circuits and no unsafe voltages are present at the sbRIO-9687 inputs. Voltages that
exceed the specifications could result in damage to the sbRIO-9687.
Caution Use the sbRIO-9687 with only sbRIO-9683 or sbRIO-9684 devices. The
sbRIO-9687 is not electrically or mechanically compatible with other NI devices.
Caution The sbRIO-9683 or sbRIO-9684 simultaneous sampled isolated AI's
common ground is short circuited to the main ground on the sbRIO-9687 interface
board when assembled, defeating the channel-to-common isolation ratings of these
circuits.
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
Verifying the Kit Contents
Verify the following components are in your kit.
• sbRIO-9687
• sbRIO power cable assembly, 9.5 in.
• (QTY 2) 10-pin flat data cable
• 2-pin power plug
• 2-pin plug for display power
2 | ni.com | sbRIO-9687 Getting Started Guide
