Hardware Overview
The sbRIO-9687 is intended to be used together with the sbRIO-9683 or sbRIO-9684 General
Purpose Inverter Controller and the sbRIO-9607 CompactRIO Single-Board Controller. These
boards are designed to be stacked with board-to-board connectors.
The following figure shows the components of the sbRIO-9687.
Figure 1. sbRIO-9687 Components
9
9
10
12
13
14
15
16
1
3
4
2
5
7
8
11
6
1. Power connector
2. Inverter connectors
3. Thermistor connector
4. Display RS232 connector
5. Display power connector
6. AO breakout connector
7. AI connectors
8. RS232 input
9. Expansion board connectors
10. HB signals breakout connector
11. DI breakout connector
12. CAN input
13. sbRIO-9607 power
14. Relay outputs
15. Feedback connectors
16. DO breakout connector
Dimensions
The following figures show the board dimensions and connector height for the sbRIO-9687.
For detailed dimensional drawings and 3D models, visit ni.com/dimensions and search for
9687.
4 | ni.com | sbRIO-9687 Getting Started Guide
