Neato Robotics botvac connected User Manual

13
Maintaining your Neato robot
IMPORTANT
Your robot needs regular maintenance
to operate reliably. This means checking/
cleaning the brushes and emptying the dirt
bin after every use or as needed, depending
on your environment. Failure to do this may
cause problems with your robot and impact
your robot’s performance and possibly
warranty coverage.
Sensors
Robot Top
Use a dry cotton
swab to clean the
two drop sensor
windows on the
bottom of the robot.
Clean the top of the robot and the area
around the laser top with a damp cotton
cloth.
Dirt Bin and Filters
After each use, empty the dirt bin, clean the
airways/openings and filter. To remove the
filter, pinch the handle and pull out.
Use the cleaning tool comb to clean the filter.
Brushes
Replace the filter
every 1 to 2 months
or more frequently
as needed.
Remove the guard over the brush by pulling
up on both sides.
Use the cleaning tool blade to cut and
remove hair and comb to remove dirt from
the brush. Clean the brush ends.Replace the
brush and guard over the brush.
PULL UP ON
BOTH SIDES
SIMULTANEOUSLY
Filter Comb
Hair/Fiber
Cutter

Neato Robotics botvac connected Specifications

General

Shape	D-shape
Product color	Black
Built-in display	Yes
Dust container type	-
Dust capacity (total)	- L
AC input voltage	110-220 V
Battery capacity	- mAh

Weight and Dimensions

Depth	321 mm
Width	335 mm
Height	100 mm
Weight	4100 g
