English−76
Chapter 7 External Control
This Chapter Includes:
> “Connecting Interfaces” on page 77
> “Controlling the Monitor via RS-232C” on page 80
> “Controlling the Monitor via LAN” on page 81
> “Intelligent Wireless Data” on page 89
> “Proof of Play” on page 90
Connecting external device
There are two options to connect an external device to control the monitor.
NEC Display Wall Calibrator or NaViSet Administrator allows you to control the monitor settings and get the monitor status,
including calibration information.
• RS-232C terminal.
Connecting an external device to the RS-232C terminal of the monitor with a RS-232C cable.
• LAN port.
Connecting a network to the LAN1 (DAISY CHAIN IN) port of the monitor with a LAN cable (RJ45 category 3 or higher).
To Next Page
