DESCRIPTION

The PF-90 / PF-80 Folder is designed to perform a wide variety of folds using a variety of paper weights. The fold tables

are automatically adjusted for standard folds and custom folds. Documents that are 8 ½” x 11”/14” and 11” x 17” (A5,

A4, A3, B4, B5 & B6) are detected by sensors on the in-feed tray. Batch counting, self-centering side guides, and the

capability to cross-fold are added features. There are six pre-programmed standard folds and up to 35 custom folds

available. The folder will automatically stop after the last document has been folded.

SPECIFICATIONS

Speed: Standard Mode: Up to 16,450/hour, depending on fold type

Thick Stock Mode: Up to 20,100/hour, depending on fold type

Hopper Capacity: Up to 500 sheets of 20# paper (75gsm)

Paper size: Min: 3.5” X 5” (88.9 W x 127 L mm)

Max: 12.25” X 18” (311 W x 457 L mm)

Pre programmed fold types: Letter , Zig-Zag , Single , Gate , Fold Out ,

Double Parallel

Pre-Set Paper Sizes: 11”, 14”, 17”, A5, A4, A3, B6, B5, B4

Languages: English, Spanish, French, German, Italian & Dutch

Dimensions Closed: 33” L x 20” W x 19” H (84 L x 51 W x 48 H cm)

Fully Extended: 60” L x 20” W x 19” H (152 L x 51 W x 48 H cm)

Weight: 74 lbs (34 kg)

Power: 120V - 240V AC, 50/60 Hz, 2.5 amps.

Safety Certications: UL & CE Applied For

Upper Fold Table

Telescoping

Outfeed Stacker

Self Centering Paper

Side Guides

Infeed Tray

Extension

Infeed Tray

Lever

Lower Fold Table

Non Operator Side

Operator Side

Multi-Sheet Feeder

(Option for PF-80)

Stacker Wheels

Top Cover

Control Panel
