NetComm NB604N – ADSL2+ Wireless N300 Modem
Router
Layer 2 Interface
The Layer 2 Interface pages allow you to add or remove ATM interfaces and configure the behaviour of the Ethernet ports.
ATM Interface
To remove a currently configured ATM Interface, Click the remove checkbox corresponding to the chosen interface and click
Remove.
To Add a new Interface, click the add button and enter the appropriate configuration information as shown below:
Enter the PVC identifier for your service. This will usually be 8/35 for users in Australia. For New Zealand users the VPI will
usually be 0 and the VCI will usually be 100.
Select the DSL latency path you wish to use.
Select the type of connection – PPPoE (EoA), PPPoA or IPoA
Select the type of connection.
Select the type of encapsulation utilised by your service. Options include LLC/SNAP-BRIDGING or VC/MUX.
Select the appropriate Quality of Service settings to apply to this connection
Click Apply/Save to save the new Interface.
