5.
From the menu on the left, select VLAN.
The VLAN page displays.
If you did not yet activate the Advanced 802.1Q VLAN mode, see Activate
the
advanced 802.1Q VLAN mode on page 47.
6. In the right pane, click the ADD VLAN button.
The Advanced 802.1Q VLAN pane displays.
7.
Specify the VLAN settings and assign ports as tagged or untagged members:
a.
In the VLAN Name field, enter a name from 1 to 14 characters.
b.
In the VLAN ID field, enter a number from 1 to 4094.
c.
Select the port tags and whether ports are members of the VLAN through a
combination of the following actions:
•
Click the T button for an individual port to make the port a tagged member
of the VLAN.
•
Click the U button for an individual port to make the port an untagged member
of the VLAN.
•
Click the E button for an individual port to exclude the port from the VLAN.
•
Click the Tag All link to make all ports tagged members of the VLAN.
•
Click the Untag All link to make all ports untagged members of the VLAN.
•
Click the Exclude All link to exclude ports from the VLAN.
Note: If ports are members of the same LAG, you must assign them to the same
VLAN.
8. Click the APPLY button.
Your settings are saved. The new VLAN shows in the Advanced 802.1Q VLAN pane.
Change an advanced 802.1Q VLAN
You can change the settings for an existing advanced 802.1Q VLAN.
To change an advanced 802.1Q VLAN:
1.
Open a web browser from a computer that is connected to the same network as the
switch, or connected directly to the switch through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
A login window opens.
User Manual49Use VLANS for Traffic
Segmentation
Gigabit Ethernet Smart Managed Plus Switches Series 3XXEP and 3XXEPP
