Technical specifications
The following are the technical specifications for your Orbi router and satellite
Technical specifications for Orbi router model RBR750
The following table shows the technical specifications for Orbi router model RBR750.
Table 8. Technical specifications for Orbi router model RBR750
DescriptionFeature
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP,
and SMB
Data and routing protocols
North America: 120V, 60 Hz, input
UK, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
All regions (output): 12V, 3.5A DC output
Power adapter
9.1 x 7.2 x 2.8 in. (231 x 183 x 71 mm)Dimensions
1.9 lb (862 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003, Class B
EN 55032, EN 55035, Class B
AS/NZS CISPR 32, Class B
Electromagnetic emissions
Compatible with 10BASE-T, 100BASE-TX, 1000BASE-T, RJ-45LAN
Compatible with 10BASE-T, 100BASE-TX, 1000BASE-T, RJ-45WAN
Maximum wireless signal rate complies with the IEEE 802.11 standard.
Note: Maximum wireless signal rate derived from IEEE Standard 802.11
specifications. Actual throughput can vary. Network conditions and
environmental factors, including volume of network traffic, building
materials and construction, and network overhead, lower actual data
throughput rate.
WiFi
2.4 GHz: Max. 600 Mbps
5 GHz fronthaul: Max. 1200 Mbps
5 GHz backhaul: Max. 2400 Mbps
Radio data rates
IEEE 802.11b/g/n/ax
2.4GHz—1024-QAM support
Data encoding standards radio 1
User Manual132Supplemental Information
Orbi Whole Home Tri-Band Mesh WiFi 6 System
