1. Ring LED (not shown in image)
2. Sync button (also used for WPS connection)
3. Internet port
4. Ethernet ports
5. Power On/Off button and Power LED
6. DC Power connector
7. Reset button
Orbi Pro satellite model SRS60 hardware overview
Figure 2. Orbi Pro satellite model SRS60, front and back views
1. Ring LED (not shown in image)
2. Sync button (also used for WPS connection)
3. Ethernet ports
4. Power On/Off button and Power LED
5. DC Power connector
6. Reset button
LED behavior
When you sync an Orbi Pro satellite to the Orbi Pro router, the LED behavior for a satellite
that comes in an Orbi Pro WiFi system is different from the LED behavior for add-on
Orbi Pro satellites.
User Manual11Overview
Orbi Pro Router Model SRR60 and Orbi Pro Satellite Model SRS60
