NXAMPMK2 USER MANUAL PAGE 61 / 80
IP BASED REMOTE CONTROL PROTOCOL
NXAMPmk2 can be remote control through an Ethernet network, using the default NXRM104 card fitted into
the NXAMPmk2 expansion slot, or one of the optional digital audio input cards, all featuring Ethernet port
for the remote control.
Both RJ45 port on the NXRM104 card are internally connected to a 100BASE-TX switch. Connect one of
the two RJ45 ports to the remote-control network. The other port can be used to daisy chain to other
NXAMPmk2 devices. Use STP (Shielded Twisted Pair) cable to prevent electromagnetic interference.
Remote control is IP based. There is no setup for IP address, it will be done automatically by the NXAMPmk2,
although more advanced IP setup can be done through the NXAMPmk2 front panel if needed. By default:
• When no DHCP server is running on the network (typical simple network with remote control computer
directly connected on the NXAMPmk2), the NXAMPmk2 will automatically choose a unique IP address.
• When a DHCP server is running on the network (typical network using a wireless router for example), a
unique IP address will be affected by the DHCP to the NXAMPmk2.
In both case user does not have to worry about IP address settings. However, it is possible to set a static IP
address to the NXAMPmk2, please refer to Remote Control Settings.
NEMO (NEXO REMOTE): NXAMPMK2 CONTROL SOFTWARE
NEXO NeMo is the remote control app of a set of NEXO products (NXAMP Powered TD-controllers, DTD
Digital TD-controllers). It allows you to control from an Apple iPad, iPhone, iPod Touch through a Wi-Fi
network and from a Mac or PC through a wired or Wi-Fi network one or many NEXO devices.
