For these measurements, the test signal is a pink noise with bandwidth limited 22 Hz to 22 kHz, all channels
driven.
Each NXAMPmk2 model (NXAMP4X1mk2, NXAMP4X2mk2 and NXAMP4X4mk2), has been measured on
three types of main power supply: 100V/50Hz, 120V/60Hz and 230V/50Hz. Please find all data below.
NOTE
1 BTU = 1055.06 J = 0.252 kcal
P(W) x 860 = cal/h
EXTENSION BOARD CONSUMPTION
Please note that all measures below have been done using the default NXRM104 extension board.
For all other extension boards, 5W must be added to the power consumption in all operating modes. For
NXAEDT, if all four network ports are used, please consider 10W instead 5W.
NXAMP4X1MK2
PINK NOISE, 100V/50HZ MAINS
MODE
Output/ch
Line
Current
(A)
Power
Consumption
(W)
Watts
Dissipated
(W)
Heat Dissipation
Power(W)
Volt(V)
Btu/h
kcal/h
Standby
0.0
0.0
0.17
6.4
6.4
22
6
Idle
0.0
0.0
1.81
167
167
570
144
Energy
saver
1/8
output
power
8ohms/ch
75.0
24.5
5.42
520
220
751
189
4ohms/ch
112.5
21.2
7.46
736
286
976
246
2ohms/ch
162.5
18.0
10.6
1058
408
1392
351
1/4
output
power
8ohms/ch
150.0
34.6
8.92
880
280
956
241
4ohms/ch
225.0
30.0
13.0
1300
400
1365
344
2ohms/ch
325.0
25.5
19.8
1946
646
2205
556
1/3
output
power
8ohms/ch
200.0
40.0
11.45
1138
338
1153
291
4ohms/ch
300.0
34.6
16.91
1688
488
1665
420
2ohms/ch
433.3
29.4
25.03
2500
767
2616
659
