Nibe F2120-16 User Manual

Sound levels
F2120 is usually placed next to a house wall, which gives a
directed sound distribution that should be considered. Ac-
cordingly, you should always attempt when positioning to
choose the side that faces the least sound sensitive neigh-
bouring area.
The sound pressure levels are further affected by walls,
bricks, differences in ground level, etc and should therefore
only be seen as guide values.
2 m
6 m
10 m
LEK
2016F2120
5555L
W
(A)Sound power level (L
WA
), according to EN12102 at 7 / 45 (nominal)
4141dB(A)Sound pressure level (L
PA
) at 2 m*
31.531.5dB(A)Sound pressure level (L
PA
) at 6 m*
2727dB(A)Sound pressure level (L
PA
) at 10 m*
* Free space.
16 NIBE F2120

Nibe F2120-16 Specifications

General

Type	Air/water heat pump
Model	F2120-16
Heating Capacity	16 kW
Operating Temperature Range	-25°C to +45°C
Refrigerant	R410A
Max Flow Temperature	65°C
Power Supply	400V
