Principle of operation
Principle of operation with hot water and a heating system.
The heating medium side and the domestic hot water side
must be fitted with the necessary safety equipment in ac-
cordance with the applicable regulations.
SYMBOL KEY
MeaningSymbol
Shut-off valve
Tapping valve
Non-return valve
Circulation pump
Expansion vessel
Filterball
Pressure gauge
P
Safety valve
Trim valve
Reversing valve/shunt
Control module
Air/water heat pump
Radiator system
Domestic hot water
Water heater
-EB101-QM1
XL1
XL2
-EB101-QM40
-EB101-QZ2
-EB101-FL10
-EB101-RM1
Heating medium connection, supply (from F2120)XL1
Heating medium connection, return (to F2120)XL2
4 NIBE F2120
